Chapter 4: Specifications
Model 8416 Mini-Direct Station Select (Mini-DSS) Unit
Page 4-48 Inter-Tel
®
5000 Installation Manual – Issue 2.4, May 2008
Model 8416 Mini-Direct Station Select (Mini-DSS) Unit
The Inter-Tel 5000 platform supports a Mini-DSS Unit that provides one-button access to 16
extension numbers and/or feature buttons/resources. The Mini-DSS attaches to a Model 8660
endpoint.
For reference, the following information matrix shows the approximate dimensions of the Mini-
DSS Unit.
Figure 4-3. Modem Data Port Module
Table 4-28. Model 8416 Mini-DSS Unit Dimensions
Dimension Measurement (Metric)
Height
1.5 in. (3.8 cm)
Width
2.6 in. (6.5 cm)
Length
7.7 in. (21.1 cm)
Weight
2.1 lb (0.13 kg)
MODEM DATA PORT MODULE
LED
INDICATORS
(stacked)
POWER CONNECTOR
PCDPM CONNECTOR
MODULAR JACK
(TOP COVER REMOVED)
TO AC TRANSFORMER
TO PC DATA PORT MODULE
TO DATA DEVICE
OR SL SET
POWER
OFF HOOK
RINGING
