Mitsubishi LANCER EVOLUTION-V 1998

CIRCUIT DIAGRAM – Power Distribution System
• WINDSHIELD
WIPER, WASHER
• REAR WIPER,
WASHER
• CIGARETTE LIGHT-
ER AND ASHTRAY
ILLUMINATION LAMP
• ELECTRIC RETRACT-
ABLE REMOTE
CONTROLLED DOOR
MIRROR
• ELECTRICALLY
REMOTE CON-
TROLLED DOOR
MIRROR
• CLOCK AND
MULTI-DISPLAY
• CENTRAL DOOR
LOCKING SYS-
TEM (VEHICLES
WITH KEYLESS
ENTRY SYSTEM)
• RADIO
• SPARE CONNEC-
TOR FOR RADIO
MULTI-
PURPOSE
FUSE
DEDICATED
FUSE (RELAY
BOX IN ENGINE
COMPARTMENT)
HORN
C-23
