REAR AXLE – Service Specifications / Lubricant / Sealant
27-2
SERVICE SPECIFICATIONS
<Vehicles with AYC>
Items Standard value Limit
Rear axle total backlash mm – 5
Pressure generated by hydraulic unit MPa {kgf/cm
2
} 0 – 1.6 {10.0 – 16.0} –
Wheel bearing axial play mm – 0.05
Wheel bearing rotation starting torque Nm {kgf@cm} – 1.0 {10.5} or less
<Vehicles without AYC>
Items Standard value Limit
Right-to-left difference in combined thickness of friction plate and fric-
tion disc mm
0 – 0.05 –
Clearance between spring plate and differential case mm 0.06 – 0.25 –
LSD differential torque
Nm {kg
f
@m}
When new clutch plate is installed 5 – 19 {0.5 – 1.9} –
N
m
{k
g
f
@m
}
When existing clutch plate is installed 2 – 19 {0.2 – 1.9} –
Distortion of friction plate and friction disc mm – 0.08
Difference in thickness between friction plate, friction disc, and spring
plate mm
– 0.1
LUBRICANT
<Vehicles with AYC>
Items Specified lubricant Capacity
Gear oil Torque
transfer
di
ff
erential
Differential MITSUBISHI GENUINE DIA QUEEN SUPER
HYPOID GEAR OIL (GL-5)
0.41 ± 0.02 dm
3
{0.41 ± 0.02 ȏ}
diff
eren
ti
a
l
Torque transfer
mechanism
MITSUBISHI GENUINE DIA QUEEN AYC FLUID
0.70
)0
*0.05
dm
3
{0.70
)0
*0.05
ȏ}
Hydraulic piping fluid MITSUBISHI GENUINE DIA QUEEN ATF-SPII 1 dm
3
{1 ȏ}
Torque transfer mechanism oil seal lips Vaseline As required
SEALANT
<Vehicles with AYC>
Items Specified sealant
Torque transfer differential vent plug Semi-drying sealant: THREEBOND 1281B (460 g)
Torque transfer mechanism cover
