MPI – Special Tools
13-4
SPECIAL TOOLS
Tool Number Name Use
MB991348 Test harness set D Measurement of voltage during trouble-
shooting
D Inspection using an oscilloscope
MB991519 Alternator harness
connector
Measurement of voltage during
troubleshooting
MB991536 TPS check
harness
Adjustment of idle switch and throttle position
sensor (TPS)
MD998464 Test harness
(4-pin, square)
Inspection of oxygen sensor
MD998463 Test harness
(6-pin, square)
D Inspection of idle speed control servo
D Inspection using an oscilloscope
MD998478 Test harness
(3-pin, triangle)
D Measurement of voltage during trouble-
shooting
D Inspection using an oscilloscope
MD998706 Injector test set Checking the spray condition of injectors
MD998741 Injector test
adaptor
MB991607 Injector test
harness
To Next Page
