MANUAL TRANSMISSION OVERHAUL
Specifications /
Service Specifications
22B-4
SPECIFICATIONS
TRANSMISSION MODEL TABLE
Transmission model Gear ratio Speedometer gear ratio Final gear ratio Front LSD
W5M51-1-X6A A 29/36 4.529 Not available
W5M51-1-X6A1 A 29/36 4.529 Available
W5M51-1-X7A A 30/36 4.529 Not available
W5M51-1-X7A1 A 30/36 4.529 Available
W5M51-1-Z6A B 29/36 4.875 Not available
W5M51-1-Z6A1 B 29/36 4.875 Available
W5M51-1-Z7A B 30/36 4.875 Not available
W5M51-1-Z7A1 B 30/36 4.875 Available
GEAR RATIO TABLE
A B
1st 2.785
2nd 1.950
3rd 1.407 1.444
4th 1.031 1.096
5th 0.761 0.825
Reverse 3.416
Transfer gear ratio 0.3018
SERVICE SPECIFICATIONS
Items Allowable range Limit
Input shaft end play mm 0.05 – 0.17
Input shaft front bearing clearance mm 0 – 0.12
Input shaft rear bearing clearance mm 0 – 0.12
Input shaft 5th speed gear clearance mm 0 – 0.09
Output shaft preload mm 0.13 – 0.18
Output shaft bearing clearance mm 0 – 0.09
Output shaft 3rd speed gear clearance mm 0 – 0.09
Center differential case preload mm 0.05 – 0.11
Center differential case pinion backlash mm 0.025 – 0.150
Synchronizer ring back surface to gear clearance mm 0.5
