MPI – Service Specifications / Sealant
13-3
SERVICE SPECIFICATIONS
Items Specifications
Basic ignition timing _BTDC 5 ± 3
Basic idle speed rpm 850 ± 50
Throttle position sensor adjusting voltage mV 400 – 1,000
Throttle position sensor resistance kΩ 3.5 – 6.5
ISC servo coil resistance (at 20_C) Ω 28 – 33
Intake air temperature sensor resistance kΩ At 20_C 2.3 – 3.0
At 80_C 0.30 – 0.42
Coolant temperature sensor resistance kΩ At 20_C 2.1 – 2.7
At 80_C 0.26 – 0.36
Fuel pressure
f
2
When vacuum hose is connected 230 {2.35}
a
g
cm
When vacuum hose is disconnected 289 – 309 {2.95 – 3.15}
Injector coil resistance Ω 2 – 3
Amount of injector fuel leak drop/min 1 or less
Oxygen sensor output voltage 0.6 – 1.0
Fuel pressure control valve coil resistance (at 20_C) Ω 28 – 36
SEALANT
Item Specified sealant
Coolant temperature sensor Drying sealant: HELMESEAL H-1M [0110513]
NOTE:
Given in [ ] are MITSUBISHI GENUINE PART numbers.
