Mitsubishi LANCER EVOLUTION-V 1998 - ANTI-LOCK BRAKING SYSTEM (ABS)

35B-1
ANTI-LOCK
BRAKING
SYSTEM (ABS)
CONTENTS
TROUBLESHOOTING 2. . . . . . . . . . . . . . . . . . . .
1. Inspection Chart for Diagnosis Codes 2. . .
2. Inspection Procedure for Diagnostic
Trouble Codes 3. . . . . . . . . . . . . . . . . . . . . . . .
3. Inspection Chart for Trouble Symptoms 11
4. Inspection Procedure for Trouble
Symptoms 12. . . . . . . . . . . . . . . . . . . . . . . . . . .
5. Check at ABS-ECU Terminals 15. . . . . . . . .
ON-VEHICLE SERVICE 17. . . . . . . . . . . . . . . .
Wheel Speed Sensor Output Voltage
Measurement <EVOLUTION-V> 17. . . . . . . . . . .
LATERAL ACCELERATION SENSOR 17. . .
WHEEL SPEED SENSOR 18. . . . . . . . . . . . . .
