Mitsubishi LANCER EVOLUTION-V 1998

BASIC BRAKE SYSTEM – Service Specifications / Lubricants
35A-2
SERVICE SPECIFICATIONS
<EVOLUTION-IV>
Items Standard value Limit
Brake booster nonboosting
action test generated
f
luid pres
-
Pedal force 98 N {10 kgf} 49 {0.5} or more –
action
test
generated
fl
u
id
pres
-
sure kPa {kgf/cm
2
}
Pedal force 294 N {30 kgf} 1,177 {12} or more –
Brake booster boosting action
test generated
f
luidpressurekPa
Pedal force 98 N {10 kgf} 2,354 – 3,334 {24 – 34} –
test
generated
fl
u
id
press
u
re
kPa
{kgf/cm
2
}
Pedal force 294 N {30 kgf} 6,963 – 9,414 {71 – 96} –
Proportioning valve Split point kPa {kgf/cm
2
} 2,697 – 3,187 {27.5 – 32.5} –
Output fluid pressure kPa {kgf/cm
2
}
(input fluid pressure kPa {kgf/cm
2
})
4,658 {47.5} (9,807 {100}) –
Front disc brake drag force N {kgf} 51 {5.2} –
Rear disc brake Brake pad thickness mm 10.0 2.0
Brake disc thickness mm 20.0 18.4
Brake drag force N {kgf} 69 {7.0} –
Brake drum I.D. mm 168.0 169.0
<EVOLUTION-V>
Same as EVOLUTION-IV except for followings.
Items Standard value Limit
Front disc brake Brake pad thickness mm 10.0 2.0
Brake drag force N {kgf} 69 {7.0} –
Rear disc brake Brake pad thickness mm 10.0 2.0
Brake drag force N {kgf} 69 {7.0} –
LUBRICANTS
Items Specified lubricant Quantity
Brake fluid MITSUBISHI GENUINE DIA QUEEN BRAKE
FLUID SUPER
As required
Piston boot, piston seal Repair kit grease
Guide pin, lock pin
Pin boot, guide pin sleeve
Piston, wheel cylinder body
Packing plate CHUO YUKA AKB100
Shoe & lining assembly
Auto adjuster assembly
