STEERING – Power Steering Fluid Cooler
37A-9
POWER STEERING FLUID COOLER
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
(1) Power Steering Fluid Draining and Refilling
(2) Front Bumper Removal and Installation
(Refer to GROUP 51.)
1
2
Unit: Nm {kgf@m}
12 {1.2}
13 {1.3}
Removal steps
1. Cooler hose
2. Power steering fluid cooler
To Next Page
