Mitsubishi LANCER EVOLUTION-V 1998

CIRCUIT DIAGRAM – Fog Lamp
FUSIBLE LINK
• CHARGING SYSTEM
• POWER SUPPLY
• HEADLAMP
DEDICATED
FUSE
COLUMN
SWITCH
(LIGHTING
SWITCH)
FOG LAMP
SWITCH
FOG LAMP
: • CLOCK, MULTI-DISPLAY
• CIGARETTE LIGHTER, ASH TRAY
ILLUMINATION LAMP
• TURNSIGNAL LAMP, HAZARD
WARNING LAMP
• ELECTRIC RETRACTABLE
REMOTE CONTROLLED MIRROR
B-44
FOG LAMP
