REAR SUSPENSION – Stabilizer Bar
34-14
STABILIZER BAR
REMOVAL AND INSTALLATION
Post-installation Operation
D Check the Stabilizer Link Ball Joint Dust Cover for
Cracks or Damage by Pushing it with Finger.
1
2
3
4
5
Unit: Nm {kgf@m}
39 {4.0}
3
39 {4.0}
39 {4.0}
20 {2.0}
Removal steps
1. Stabilizer link mounting nuts
2. Stabilizer link
"AA 3. Stabilizer bar bracket
"AA 4. Bushing
"AA 5. Stabilizer bar
To Next Page
