CIRCUIT DIAGRAM – Engine Control System
FUSIBLE LINK
FUSIBLE LINK IGNITION SWITCH (IG1)
VACANT
TERMINAL
COMBINATION
METER
ENGINE
CONTROL
RELAY
ACTIVE YAW
CONTROL SYSTEM
ANTI-LOCK
BRAKE
SYSTEM
ENGINE-ECU
POWER SUPPLY
BACK-UP
POWER
SUPPLY
B-34
ENGINE CONTROL SYSTEM
