27-1
REAR AXLE
CONTENTS
SERVICE SPECIFICATIONS 2. . . . . . . . . . . . . .
LUBRICANT 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SEALANT 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIAL TOOLS 3. . . . . . . . . . . . . . . . . . . . . . . .
TROUBLESHOOTING
<A
YC>
5
. . . . . . . . . . . . . ON-VEHICLE SERVICE
<VEHICLES WITH AYC> 27. . . . . . . . . . . . . . .
1. Rear Axle Total Backlash Check 27. . . . . . .
2. Gear Oil Level Check 27. . . . . . . . . . . . . . . .
3. Gear Oil Change 28. . . . . . . . . . . . . . . . . . . . .
4. Fluid Level Check 29. . . . . . . . . . . . . . . . . . . .
5. Bleeding 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6. Differential Carrier Oil Seal
Replacement 30. . . . . . . . . . . . . . . . . . . . . . . . .
7. Speed Sensor Output Voltage
Measurement <Vehicles without ABS> 31.
8. Action When Battery Runs Out 32. . . . . . . .
REAR HUB ASSEMBLY 33. . . . . . . . . . . . . . . .
KNUCKLE 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DRIVE SHAFT 36. . . . . . . . . . . . . . . . . . . . . . . . .
DIFFERENTIAL CARRIER
<EVOLUTION-IV, EVOLUTION-V GSR> 39.
DIFFERENTIAL CARRIER
<EVOLUTION-V RS> 41. . . . . . . . . . . . . . . . . . .
TORQUE TRANSFER DIFFERENTIAL
<VEHICLES WITH AYC> 43. . . . . . . . . . . . . . .
LSD CASE ASSEMBLY
<VEHICLES WITHOUT AYC> 46. . . . . . . . . . .
HYDRAULIC UNIT
<VEHICLES WITH AYC> 50. . . . . . . . . . . . . . .
SENSOR RELAY
<VEHICLES WITH AYC> 52. . . . . . . . . . . . . . .
AYC-ECU 53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
