MPI – Special Tools
13-5
Tool UseNameNumber
MD998746 Clip Checking the spray condition of injectors
MD998709 Adaptor hose Measurement of fuel pressure
MD998742 Hose adaptor
MB991637 Fuel pressure
gauge set
Red harness
White harness
MB991223 Inspection test
herness set
D Pin contact
pressure
inspection
harness
D Market tester
contact probe
(for general
connectors)
Measurement of terminal voltage
MB991529 Diagnostic trouble
code check har-
ness
Reading of diagnosis codes
MB991709 Test harness D Measurement of voltage during trouble-
shooting
D Inspection using an oscilloscope
