MPI – Troubleshooting
13-16
Code No. 64 Alternator FR Terminal System Probable cause
Range of Check
D Engine speed is approximately 50 r/min or more.
Set conditions
D Input voltage at the alternator FR terminal is 4.5 V or more for 20 seconds.
D Open circuit in alternator FR terminal circuit
D Malfunction of the engine-ECU.
OK
Replace the alternator.
NG
Check the harness wire between
the engine-ECU and alternator
connector.
NG
Repair
OK
Check trouble symptom.
Measure at the alternator connec-
tor
D Connect the connector.
(Use test harness MB991519.)
D Voltage between 4 (blue clip)
and earth
(Engine: Idling)
(Radiator fan: Stopped)
(Headlamp: OFF → ON)
(Brake lamp: OFF → ON)
(Rear defogger switch: OFF
→ ON)
OK: Voltage drops by 0.2 to
3.5 V.
NG
Measure at the alternator connec-
tor A-05.
D Disconnect the connector, and
measure at the harness side.
D Voltage between 4 and earth
(Ignition switch: ON)
OK: 4.8 – 5.2 V
NG
Check the following connec-
tors:
B-60, A-88
NG
Repair
OK
Check trouble symptom.
NG
Check the harness wire between
the engine-ECU and alternator
connector.
NG
Repair
OK
Replace the engine-ECU.
OK
Check the following connector:
A-05
NG
Repair
OK
Replace the engine-ECU.
To Next Page
