MANUAL TRANSMISSION OVERHAUL – Transfer
22B-50
REASSEMBLY SERVICE POINTS
"AA O-RING INSTALLATION
Apply transmission oil to the O-ring.
Transmission oil: DIA QUEEN MULTI-GEAR OIL 75W/85W
"BA OIL SEAL INSTALLATION
(1) Apply transmission oil to the oil seal lip area.
Transmission oil:
DIA QUEEN MULTI-GEAR OIL 75W/85W
(2) By using the special tool, install the oil seal.
"CA OIL SEAL INSTALLATION
(1) Apply transmission oil to the oil seal lip area.
Transmission oil:
DIA QUEEN MULTI-GEAR OIL 75W/85W
(2) By using the special tool, install the oil seal.
"DA OIL SEAL INSTALLATION
(1) Apply transmission oil to the oil seal lip area.
Transmission oil:
DIA QUEEN MULTI-GEAR OIL 75W/85W
(2) By using the special tool, install the oil seal.
"EA OIL SEAL INSTALLATION
(1) Apply transmission oil to the oil seal lip area.
Transmission oil:
DIA QUEEN MULTI-GEAR OIL 75W/85W
(2) By using the special tool, install the oil seal.
MD998800
MB990938
MB990933
MB990891
MB990887
MD998304
To Next Page
