STEERING – Power Steering Gear & Linkage
37A-4
DISASSEMBLY AND REASSEMBLY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
33
20
35
22
23
24
25
26
27
29
31
Unit: Nm {kgf@m}
22 {2.2}
30
34
49 – 59
{5.0 – 6.0}
28
19
21
59 {6.0}
25 {2.5}
59 { 6.0}
1
13 {1.3}
88 {9.0}
7
32
10
2
22
20
18
7
10
34
16
30
31
28 27
Steering gear seal kit
Flare nut
Repair kit grease
Disassembly steps
1. Feed pipe
2. O-ring
"NA 3. Lock nut
"NA 4. Tie rod end
"MA 5. Dust cover
6. Clip
"LA 7. Band
8. Bellows
"KA 9. Tie rod
"KA 10. Tab washer
"JADPinion total turning torque adjustment
11. Lock nut
AA" 12. Rack support cover
13. Support spring
14. Rack support
"IA 15. End plug
16. Lock nut
17. Valve housing assembly
AB""HA 18. Lower oil seal
AB" 19. Pinion & valve assembly
AC""GA 20. Seal ring
AD""FA 21. Upper bearing
AD""FA 22. Upper oil seal
23. Valve housing
AE""EA 24. Circlip
AF" 25. Rack stopper
AF""DA 26. Rack bushing
AG""DA 27. Oil seal
28. O-ring
AF""CA 29. Rack assembly
AC" 30. Seal ring
31. O-ring
AH""BA 32. Lower bearing
AI""BA 33. Needle bearing
AJ""AA 34. Oil seal
35. Gear housing
To Next Page
