BODY –
Body Dimension
42-8
21
7, 81
indicates that the dimension and the measurement point are the same as those for EVOLUTION-IV.
1,273
10
1
8
7
9
3
2
900
21
6
4
1,393
1,222
1,627 1,028
961
869
9, 10
Unit: mm
8 7
9
10
No. Standard measurement point Hole _ Size
shape mm
No. Standard measurement point Hole _ Size
shape mm
1*
Rear portion of front bumper stay mounting hole f – 30
7
Center bearing mounting bolt end –
2*
Center of suspension crossmember mounting hole Left: f – 14
Right: f – 16
8
Center bearing mounting bolt end –
3*
Rear portion of front floor sidemember positioning hole f – 25
9
Center bearing mounting bolt end –
4*
Rear portion of rear seat crossmember positioning hole
– 22 × 38
10
Center bearing mounting bolt end –
6*
Center of rear floor sidemember extension drain hole f – 20
21
Center of suspension crossmember mounting hole f – 14
NOTE: The * mark indicates the mounting position for the frame centering gauge.
