BODY –
Body Dimension
42-14
2, 13
65
2012
indicates that the dimension and the measurement point are the same as those for EVOLUTION-IV.
13
2
21
22
21, 22
No. Standard measurement point Hole _ Size
shape mm
No. Standard measurement point Hole _ Size
shape mm
2
Center of suspension crossmember mounting hole Left: f – 14
Right: f – 16
21
Center of suspension crossmember mounting hole f – 14
12
Center of suspension crossmember mounting hole f – 15
22
Center of suspension crossmember mounting hole
Left: f – 13.5
Right: – 12.2 × 14
13
Center of suspension crossmember mounting hole f – 16
65
Trailing arm mounting position –
20
Differential mounting bolt end –
70
Control link mounting position –
