Moons' MBDV Series - 2 Basic Information; Product Confirmation; Drive Model Introduction; Drive Model Description

11
Rev. 2.0
07/27/2023
MBDV Hardware Manual
2 Basic Information
2.1 Product conrmation
Please refer to the following chapters to conrm the model of the driver and the model of the servo
motor. A complete operational servo should include the following components:
●
Power-matched servo drives and servo motors
●
Mini for USB to PC _ USB communication cable (optional)
●
Wireless communication module for Wireless port (optional)
●
Connector for I/O port (standard item)
●
Encoder signal frequency division output connector for Encoder output port (for Dual axis
driver, standard product)
●
STO connector for STO port (standard item)
●
Connectors for COM1 and COM2 ports, for CAN Open or RS485 communication
(standard)
2.2 Drive model introduction
2.2.1 Drive model description
MBDV - 2X - 5 20A C -
***
① ② ③ ④ ⑤
① MBDV Series ④ Current
② # of Axes 20A: Continuous Curent 20A (RMS)
Empty: Single axis Peak Cureent 60A (RMS)
2X: Dual axis ⑤ Communication Protocol
③ Input Voltage C: CANopen
、
RS485
5: 24 ~ 60VDC ⑥ Custom Code
