MBDV Hardware Manual
1 Introduction
1.1 About this manual
This manual is the hardware manual of MBDV series low voltage servo driver. It provides
installation, conguration and basic operation of MBDV servo unit. This document is intended for
qualied personnel who transport, assemble, and maintain this equipment.
1.2 MBDV Series Low Voltage Servo Documentation
This manual is part of a series of documents, the entire series consists of the following:
●
MBDV series low voltage servo hardware manual. Details hardware installation, conguration
and operation.
●
CANopen communication manual. Describes the CANopen communication function of the drive-
in detail.
●
Modbus communication manual. Detailed introduction to drive Modbus R
TU communication
function.
●
Luna software user manual. Introduce how to use the Luna software.
1.3 Safety
To prevent hazards to people and damage to property, installation should only be performed by
qualied personnel.
MBDV series low voltage servo products use dangerous voltage. The drive must be
properly grounded.
Before you install MBDV series low voltage servo products, please read the product manual
carefully. Failure to follow safe operating instructions may result in personal injury or equipment
damage.
1.4 Safety sign
Safety signs indicate potential personal hazards or equipment damage, such as failure to follow
recommended precautions and actual safe practices. The following are cautionary safety symbols
used in this manual and on the drive:
Caution Dangerous Voltage Earth Caution,Hot Surface
