1.5 Safety Precautions
1.5.1 Storage
Please note the following when storing:
◆
Please put this drive in the packing box and store it in a dry, dust-free place away from direct
sunlight
◆
Storage ambient temperature between -20
℃
to +65
℃
◆
Storage environment humidity is in the range of 10% to 85% without condensation
◆
A
void storage in corrosive atmospheres
1.5.2 Installation Precautions
◆
It is forbidden to use this product in the environment with moisture, corrosive gas, ammable and
explosive
◆
Do not use this product in places with strong vibration and shock
◆
Do not use cables immersed in water or oil
◆
Do not squeeze or stress the cable to avoid dangerous situations such as electric leakage caused
by damage to the cable.
◆
Do not block the heat dissipation holes of the driver, and avoid metal chips and other conductive
objects entering the driver during installation
◆
Do not directly touch the rotating motor shaft with your hands
◆
Do not knock the motor during installation, so as not to damage the motor shaft or the internal
optical encoder
◆
In the rst test run, rst separate the coupling or belt of the mechanical equipment, so that the motor
is in a no-load state
◆
Incorrect parameters will cause abnormal operation under load
◆
The temperature of the drive radiator, motor
, and external regeneration resistor will rise during
operation, please avoid touching
◆
Do not lift the motor lead wire during transportation and installation
1.5.3 Wiring Precautions
◆
Do not connect the power grid to the UVW motor terminal on the drive side, it will damage the drive
or cause a re
◆
Please connect the output UVW of the driver and the UVW of the servo motor directly, and do not
pass the electromagnetic contactor in the middle.
◆
Please tighten the xing screws of the power supply and motor output terminals, otherwise it may
cause re
◆
Do not switch the main power supply of the driver frequently
. If you really need to switch the power
supply repeatedly, please control it to less than 1 time per minute.
◆
Avoid bundling the main circuit cable with the input and output signal cables.
◆
Please use twisted pair shielded wire for input signal wire and encoder signal wire
◆
Please use the specied power supply voltage
◆
One wire insertion port of the terminal block, please insert only one wire
◆
When inserting the wire, do not short the core wire with the adjacent wire
◆
Be sure to ensure that the driver power supply and motor are well grounded
◆
Before powering on, make sure all wiring is correct
