Moons' MBDV Series - Page 137

137
Rev. 2.0
07/27/2023
MBDV Hardware Manual
Parameter Instruction Name Defaults Range Unit
Related
Patterns
P1-34 RT Current Ramp Limit 1000 00 ~ 3000 0.1% P S T
The rst speed value in multi-speed mode for multi-speed control, please refer to the chapter 7.2.13 multi-stage speed control mode
Parameter Instruction Name Defaults Range Unit
Related
Patterns
P1-37 DV Dynamic brake velocity 50 0 ~50 rps P S T
The maximum speed at which the dynamic brake can be activated.
Parameter Instruction Name Defaults Range Unit
Related
Patterns
P1-38 DW Dumping Voltage Setting 650 200 ~ 850 0.1V P S T
Sets or request dumping voltage level for MBDV drives. When voltage is above set level, regen resistor will be triggered
Parameter Instruction Name Defaults Range Unit
Related
Patterns
P1-39 ZS Watchdog trigger time 500 0 ~ 10000 ms P S T
Sets or requests the amount of time before a communication loss is detected. The internal timer is reset when a new network
application message is received and then proceeds to counts down. When the internal timer reaches zero, the action set by
ZA is performed.
Parameter Instruction Name Defaults Range Unit
Related
Patterns
P1-40 ZA Action after the watchdog is triggered 1 1 ~ 16
——
P S T
Sets or requests the action taken when communication loss has been detected.
