MultiTrode MultiSmart User Manual

MultiSmart Installation & Operation Manual
Fault Name Description
Default
Setting
Default
Status
Section
Reference
Pump 1 VFD Comms Fail
The MultiSmart is unable to communicate to the VFD
-
On
23.4
Pump 1 VFD Fault
The VFD has returned a fault
-
On
23.4
Pump 1 VFD Warning
The VFD has returned a warning
-
On
23.4
Groups
Group 1 Blocked Pump Detection
Number of Standby pump starts equals the specified maximum
3
Off
16
Group 1 Pulse Start
A group based Pulse Start has been initiated
-
Off
16.2.3
Group 1 Pulse Stop
A group based Pulse Stop has been initiated
-
Off
16.2.3
Well Faults
High Inflow
If level rises > a specified amount within a preset time, lead pump is pulse started
10%, 2min
Off
16
Overflow
The level is greater than the specified Overflow level (Flow module must be enabled)
100%
Off
20.1
Well 1 Analog Compare Fault
The difference in the level between the primary and the backup level devices is greater
than the specified threshold.
5% Off 14.8.11
Well 1 Level Locked
The level has changed by less than the specified amount in the specified time. (The
timed period can be a fixed amount of time or a period of the day, e.g. 14:30 to 17:00).
Up to four timed periods can be specified.
5%, 30min Off 14.8.12
Well 1 High High Level
Level has reached the High High level
96.0 - 98.0
Off
12.3.4
Well 1 High Level
Level has reached the High level
87.0 - 92.0
On
12.3.40
Well 1 Low Low Level
Level has reached the Low Low level
4.0 - 6.0
Off
12.3.4
Well 1 Low Level
Level has reached the Low level
10.0 - 15.0
Off
12.3.4
Well 1 Backup Level Ain Over Range
The current of backup level device is greater than specified maximum
20mA
On
-
Well 1 Backup Level Ain Under Range
The current of backup level device is less than the specified minimum
4mA
On
-
Well 1 Backup Level Invalid
Communications to the backup remote level has failed
-
On
-
Well 1 Primary Level Ain Over Range
Primary level device current is greater than the specified maximum
20mA
On
14.6
Well 1 Primary Level Ain Under Range
Primary level device current is less than the specified minimum
4mA
On
14.6
Well 1 Primary Level High Range
Primary Level < HRP and Backup level > HRB
HRP = High Range Primary level, HRB = High Range Backup level
80%, 95%,
5s
On 14.8.9.1
Well 1 Primary Level Invalid
Communications to the primary remote level has failed
-
On
Well 1 Primary Level Low Range
Primary Level > LRP and Backup level < LRB
LRP = Low Range Primary level, LRB = Low Range Backup level
15%, 5%,
5s
On 14.8.9.2
Well 1 Pulse Start
A well based Pulse Start has been initiated
-
Off
16.2.3
Well 1 Pulse Stop
A well based Pulse Stop has been initiated
-
Off
16.2.3
Station Faults
Max Off Time
4
Off time of any pump is greater than the specified maximum
6h
Off
16
Max Run Time
4
The run time of any pump is greater than the specified maximum
30min
Off
16
Power Failure
A user definable fault (A link or source required)
-
On
-
Station Inhibited
5
Activated via SCADA - all pumps in station become unavailable (‘Inhibit’ flashes)
-
On
-
Station Pulse Start
A station based Pulse Start has been initiated
-
Off
16.2.3
Station Pulse Stop
A station based Pulse Stop has been initiated
-
Off
16.2.3
Station Low Flow Fault
Station Flow rate is lower than the expected flow rate by an amount of preconfigured
percentage of the expected flow
100% Off 20.5
Station Low Flow Warning
Station Flow rate is lower than the expected flow rate by an amount of preconfigured
120%
Off
20.5
MultiSmart_IO_Manual_R20 Page 239 of 260
