Room Monitor
Listen to the sounds at another extension.
Use Room Monitor to monitor the sounds at another extension. In a residential setting, a typical residential application is to
listen for sounds in an infant’s room. In a commercial setting, you can use Room Monitor to listen for activity at a reception
area or warehouse entrance.
To set up Room Monitor:
1. Enable Room Monitor at the keyset extension you wish to monitor.
2. At your extension, place an Intercom call to the monitored extension.
You can hear everything picked up by the monitored extension’s microphone. You can place and answer calls normally and
automatically return to monitoring when you hang up. Additionally, you can press a soft key to make an Intercom call to the
monitored extension, or press a different soft key to end monitoring and return to normal operation.
The extension you are monitoring is completely dark and quiet except for an illuminated (green) DND key. Incoming ringing,
paging, and voice announcements are disabled and the Feature Key LEDs are off. The monitored extension user can place
calls and return automatically to being monitored when they hang up. In addition, a person at the monitored extension can
press a soft key to call you on the Intercom, or press a different soft key to end the Room Monitor session.
Up to 7 extensions can simultaneously monitor the same extension.
Room Monitor with Call Coverage, Hotline, or Reverse Voice Over Keys
These keys simplify Room Monitor operation by providing you with one-button access and a unique Busy Lamp Field (BLF)
for the monitored extension.
Call Coverage, Hotline, and Reverse Voice Over Key Busy Lamp Indications
The covered extension is:Room Monitor at the destination is:
When the key is:
IdleDisabledOff
Busy on a call (all types) or ringing
(Hotline and Reverse Voice Over
only) (Also see Slow Flash below)
DisabledOn (red)
Idle or being monitored by another
extension
EnabledOn (orange)
Being monitored by youEnabledOn (green)
(Call Coverage key only) Ringing for
an incoming call
DisabledSlow Flash (red)
Using Room Monitor
To enable Room Monitor at an extension:
1. Press
DND + Push Room Monitor (Mon).
2. DND is on (green) while Room Monitor is active.
3. While your extension is being monitored:
a) Your display shows:
Monitored by (name or extension number) (if more than one extension is monitoring your phone).
Monitoring phone in use (if the extension monitoring your phone is busy on a call).
DSX | Features | 161
