NETGEAR GS324T User Manual

S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Configure Switching User Manual157
the priority is set to the priority is automatically set to the next lowest priority that is a
multiple of 16. For example, if you set a value between 0 and 15, the priority is set to
0. If you specify a number between 16 and 31, the priority is set to 16. Specify a value
in the range from 0 to 240.
• Port Path Cost. Set the path cost to a new value for the specified port in the selected
MST instance. Specify a value in the range from 0 to 200000000.
10. Click the Apply button.
Your settings are saved.
11. To refresh the page with the latest information about the switch, click the Refresh button.
The following table describes the read-only MST port configuration information displayed on
the Spanning T
ree CST Configuration page.
Table 39. MST port status information
Field Description
Operational Port Path Cost Indicates the operational path cost that is based on the link speed of the port if
the configured value for Port Path Cost is zero.
Auto Calculated Port Path
Cost
Indicates whether the path cost is automatically calculated (Enabled) or not
(Disabled). Path cost is calculated based on the link speed of the port if the
configured value for Port Path Cost is zero.
Port ID The port identifier for the specified port within the selected MST instance. It is
made up from the port priority and the interface number of the port.
Port Up Time Since Counters
Last Cleared
The time since the counters were last cleared, displayed in days, hours,
minutes, and seconds.
Port Mode The Spanning Tree Protocol administrative mode that is associated with the port
or port channel.
The option is Enable or Disable.
Port Forwarding State The current STP state of a port. If enabled, the port state determines what
forwarding action is taken on traffic.
The options are as follows:
• Disabled. STP is currently disabled on the port.
The port forwards traf
fic
while learning MAC addresses.
• Blocking.
The port is currently blocked.
The port cannot forward traffic nor
can it learn MAC addresses.
• Listening.
The port is currently in listening mode.
The port cannot forward
traffic nor can it learn MAC addresses.
• Learning.
The port is currently in the learning mode.
The port cannot
forward traffic. However, it can learn new MAC addresses.
• Forwarding.
The port is currently in the forwarding mode.
The port can
forward traffic and learn new MAC addresses.
Port Role Each MST bridge port that is enabled is assigned a port role for each spanning
tree. The port role can be Root Port, Designated Port,
Alternate Port, Backup
Port, Master Port, or Disabled Port.
Designated Root The root bridge for the selected MST instance. It is made up using the bridge
priority and the base MAC address of the bridge.

NETGEAR GS324T Specifications

General

Switch type	Managed
Switch layer	L2/L3/L4
ARP inspection	Yes
Master (outer) case width	270 mm
Master (outer) case height	271 mm
Master (outer) case length	481 mm
Master (outer) case weight	8850 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	3 pc(s)
Package type	Box
Package depth	465 mm
Package width	229 mm
Package height	79 mm
Package weight	2710 g
Cables included	AC
Stackable	-
Product color	Black
Input current	5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	13.5 W
Operating temperature (T-T)	0 - 40 °C
MAC address table	16000 entries
Power connector	AC-in jack
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Private VLAN, Voice VLAN, Port-based VLAN
DHCP features	DHCP client

Weight and Dimensions

Depth	169 mm
Width	328 mm
Height	43 mm
Weight	1620 g
