NETGEAR S3300 User Manual

Getting Started
22
S3300 Smart Managed Pro Switch
• Microsoft Edge
• Mozilla Firefox version
s 40, 46.0.1
• Chrome version 45
• Safari on Windows OS 5.1,
6.0
• Safari on Mac OS 8.0
 To log on to the web interface:
1. Op
en a web browser and enter the IP address of the switch in the web browser address
field.
The login screen displays.
2. T
ype the password in the Password field.
The factory default password is p
assword. Passwords are case-sensitive.
3. Click the L
ogin button.
After the system authenticates you, the System Information screen displays.
The following figure shows the layout of the web interface.
Navigation tab Configuration menus
Logout button
Help link
Buttons
Screen menu
Configuration status and options
Help screen
Figure 7. Smart Switch Web Interface

NETGEAR S3300 Specifications

General

Model	NETGEAR S3300
Category	Switch
VLAN Support	Yes
Quality of Service (QoS)	Yes
MAC Address Table Size	16K
Uplink Ports	4 x 10G SFP+
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	Layer 2+/Layer 3 Lite
Management	Web-based GUI, SNMP
Dimensions	440 x 257 x 43 mm (17.32 x 10.12 x 1.69 in)
Jumbo Frame Support	Yes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	90% maximum relative humidity, noncondensing
Power Supply	Internal power supply
Power Consumption	Varies by model
Ports	24 or 48 x 10/100/1000BASE-T
Weight	3.60 kg (7.94 lb)
