Notifier AFP-200 Installation Manual

Programming Releasing Zones Releasing Applications
AFP-200 PN 15511:H2 10/14/2002 149
D.2.1 Releasing Zone Functions
Releasing zone functions include the following:
• Delay Timer
• Abort Timer
• Cross Zone
• Soak Timer
D.2.2 Delay Timer
A Delay Timer lets you program a delay time (0-60 seconds; 00=no delay timer) for
output devices mapped to a releasing zone. In Figure 142 for example, SLC control
modules M01 and M02 are mapped to releasing zone Z91. If Z91 is programmed for a
delay time of 30 seconds, M01 an M02 do not activate until 30 seconds after Z91
activates.
Figure 142 Mapped Devices to a Releasing Zone
When using a Delay Timer, note the following:
• If cross-zoning is selected for the releasing zone, the delay timer starts when two or
more devices are in alarm (for more information, refer to “Cross Zoning”).
• If abort or manual release type monitor modules are mapped to this zone they
affect the timer operation as described in “Abort Timer”.
D.2.3 Cross Zoning
Cross Zoning lets you program the control panel to activate a releasing zone and any
output mapped to the releasing zone. (If not using Cross Zoning, set CROSS= to N.)
Table 55 summarizes the types of cross zoning and the conditions for activating a
releasing zone and Table 56 shows an example of a cross zoning application.
Table 55 Cross Zoning Types
Note: Only the first non-special zone listed in the zone map is used to determine
Cross=Z.
Type Activates when...
Y Two or more detectors are alarmed that are mapped to one of the four releasing zones
(Z91-Z94).
Z Two or more detectors are alarmed that are mapped to two different software zones
and mapped to one of the four releasing zones (Z91-Z94).
H At least one smoke detector mapped to one of the four releasing zones (Z91-Z94) is
alarmed and at least one heat detector mapped to one of the four releasing zones
(Z91-Z94) is alarmed.
Z91
M01
M02
PROGRM RELEASE CKT
Z91 Z Z Z Z
** M01
PROGRM RELEASE CKT
Z91 Z Z Z Z
** M02
PROGRM SMOKE (ION)
Z91 Z Z Z Z
*P* D01
Technical Manuals Online! - http://www.tech-man.com

Notifier AFP-200 Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Auxiliary Power Output	24 VDC, 500 mA
Operating Temperature	32°F to 120°F (0°C to 49°C)
Display	80-character LCD
Power Supply	120 VAC, 60 Hz
Capacity	198 addressable devices
Notification Appliance Circuits	2
Relay Contacts	3 (Form-C)
Relative Humidity	93% non-condensing
