Programming Status Change Options
92 AFP-200 PN 15511:H2 10/14/2002
3.4.10 How to Check the Program (8=CHECK)
When finished programming the control panel, use the Check option to search program
entries for possible errors. From the Program Change screen (Figure 53 on page 71),
select option 8, (Check). The control panel software searches the program for the
following conditions:
• Output points mapped to a zone with no inputs mapped.
• A zone with programmed input point(s) without programmed output point(s),
including Z00 (general alarm) outputs.
• Releasing zone inputs (91, 92, 93, and 94) with no
RELEASE CKT outputs
programmed to them; or
RELEASE CKT outputs with no releasing zone (91-94)
inputs programmed to them.
•
RELEASE CKT inputs not mapped to MAN RELEASE.
If multiple devices fail the check, use the up or down keys to step through the devices.
To correct any errors detected by the Check routine, return to point programming and
correct the program errors.
Figure 83 shows a sample screen that appears when the system successfully completes
a Program Check.
Figure 83 Program Check Screen
3.5 Status Change Options
3.5.1 Overview
Even though control program
parameters may display in
Status Change, the operator
cannot access functions that
affect basic operation of the
control panel.
Status Change provides a second set of options accessed using the Status Change
password (“Programming Passwords” on page 66). The Status Change options only
allow change of operating parameters (listed in Table 29) that do not affect the basic
configuration or control program. For instance, assign the Status Change password to
persons who do not need to program applications or use the Autoprogram option.
This section covers the following Status Change topics:
Table 29 Status Change Topics
Program Change
Password
PROGRAM CHECK OK.
RE-TEST PANEL NOW
05:31P MON 11/03/97
Topic Refer to
Disable or enable a
detector, module, or Panel
Circuit point.
“How to Disable or Enable a Point (1=disable)” on page 95
Change detector
sensitivity for an intelligent
photo or ion detector
“How to Set Detector Selections (2=sens/comp)” on page 96
Clear verification counters
used with the Alarm
Verification feature
“How to Clear Alarm Verification Counters (3=clr ver)” on page 97
Clear history from
memory
“How to Clear the History Buffer (4=clr hist)” on page 98
Set system time and date “How to Set the System Time and Date (5=time)” on page 98
Walk test the system “How to do a Walk Test (6=walk test)” on page 99
