Combination Fire/Burglary Applications Operation
160 AFP-200 PN 15511:H2 10/14/2002
3. If needed, program additional sounders or output devices to activate when a
security condition occurs.
Repeat steps 1–3 for each monitor module security device. You can also use the
Disable/Enable function to bypass security zones for burglar applications.
E.4 Operation
E.4.1 Overview
A security type circuit indicates an alarm on an open or short circuit, or a resistance
change of ±50% from the end-of-line resistor value. Security signals latch and may
have their own Control-by-Event. They do not cause resound of alarms or reactivation
of silenced alarm CBE. Supervisory circuits may also report open circuit troubles,
which operate like any other trouble. The security LED reports the same as a
supervisory LED, but the LCD display will show the BURGLAR ALA type code.
E.4.2 Configuring the Keypad for a Security LED Indicator
The control panel is supplied with a unique security keypad slide-in label for
combination fire/burglary applications. This security label is identical to the standard
slide-in label, except the fourth label position shows “Security” in place of
“Supervisory”. On any burglar alarm, the Supervisory LED, as well as normally-open
contacts on TB3 terminal 1 and TB3 terminal 2, will activate.
Note: A combination fire/burglary listing does not include supervisory service.
E.4.3 Control Panel Operation in a Security Condition
A security condition, activated by a monitor module programmed as BURGLAR ALA,
causes the following to occur:
• The yellow Security LED lights.
• The panel LCD display indicates a burglar alarm or door tamper condition (Figure
150).
Figure 150 Typical Panel LCD Display in a Security Condition
• The panel sounder pulses until acknowledged.
• Additional sounders or output devices programmed to activate on security
condition.
When the system is reset a 30-second exit timer starts. During this time, the tamper
switch and all burglar alarm type alarms are ignored. There is no entrance delay timer.
ACTIVE@BURGLAR ALA
MODULE ADDRESS 37
FLR@5@MAIN@BUILDING
11:13A@12/25/97@M37
Label of the first zone
Status banner “Active”
Security type code
