Special Zones Time Control
168 AFP-200 PN 15511:H2 10/14/2002
H.3 Time Control
Note: All active Time Control outputs will turn off temporarily while resetting or
programming the control panel.
All outputs with a CBE equation containing Z95 or Z96 activate within the times
specified for the days of the week listed in Z95 or Z96. All smoke detectors with a CBE
equation containing Z95 or Z96 switch to their lowest sensitivity (2.0%) within the
times specified for the days of the week listed in Z95 or Z96.
Time Control is active for all days of the week listed in Z95 or Z96. Holidays listed in
Z97 are excluded unless you list Holidays (H) in the day-of-week selection. Enter the
time in a 24-hour format with the OFF time later than the ON time. After changing
programming using Time Control, always reset the control panel.
H.4 NAC Code Types
Control panel Notification Appliance Circuits with a CBE equation that includes Z98
are coded when activated by a fire alarm. These circuits are steady when activated
exclusively by an initiating device with a Hazard Alert Type Code. If using these NACs
for releasing or zone coding, do not include Z98 in the CBE equation. Select the code
type on a system basis, through special zone Z98. Table 61 contains coding selections:
Table 61 NAC Code Type Selections
Note: The control panel automatically sends an alert signal to any of the four
Notification Appliance Circuits mapped to Z00 and Z98, but not mapped to the alarm
signal. After 5 minutes without an Acknowledge or Silence, the alert signal becomes
Temporal pattern.
Two-stage Canada functions like standard Two-Stage except only the Manual Evacuate
will cause NAC to go to second stage. If acknowledge is pressed on first stage, timer
will not time out. Subsequent alarm will restart timer.
Code Type Signal
March Time (default) 120 PPM (Pulses Per Minute)
Two-Stage Alert signal – 20 PPM; General alarm signal: Temporal (see Note
below).
Two-Stage Canada 3 Alert signal – 20 PPM; Drill Switch: Temporal
Timer: 3 minutes
Two-Stage Canada 5 Alert signal – 20 PPM; Drill Switch: Temporal
Timer: 5 minutes
California 10 sec. on, 5 sec. off, repeats
Temporal 0.5 sec. on, 0.5 off, 0.5 on, 0.5 off, 0.5 on, 1.5 off, repeats
