Notifier AFP-200 Installation Manual

NFPA Applications Section Overview
132 AFP-200 PN 15511:H2 10/14/2002
Appendix B NFPA Applications
B.1 Section Overview
B.1.1 Specific Requirements
The control panel is designed for use in commercial, industrial, and institutional
applications and meets the requirements for service under the National Fire Protection
Association (NFPA) Standards outlined in this appendix. The minimum system
components required for compliance with the appropriate NFPA standard are listed
below.
• AFP-200 control panel containing the main circuit board, cabinet (backbox and
door), main supply transformer and power supply.
• Batteries (refer to Appendix A for standby power requirements).
• Initiating devices connected to the control panel’s signaling line circuit.
• Notification appliances connected to the control panel’s Notification Appliance
Circuit or via a control module.
B.1.2 Additional Requirements
Table 50 contains additional equipment that is needed for compliance with the NFPA
standards listed below:
Table 50 Additional Equipment for NFPA Applications
NFPA Standard Application Refer to
NFPA 72 Central
Station Fire Alarm
Systems
(Protected
Premises Unit)
DACT Universal Digital Alarm
Communicator/Transmitter or Notifier 911AC
DACT for connection to a compatible
UL-listed Central Station DACR or Protected
Premises Receiving Unit.
“Central Station Fire
Alarm Systems
(Protected Premises)” on
page 133
NFPA 72 Auxiliary
Fire Alarm System
RTM-8 Relay Transmitter Module or 4XTM
Transmitter Module for connection to a
compatible UL-listed Local Energy Municipal
Box.
“NFPA 72 Auxiliary Fire
Alarm System” on page
135
NFPA 72 Remote
Station Fire Alarm
System
RTM-8 Relay Transmitter Module or 4XTM
Transmitter Module for connection to the
Fire•Lite RS-82 Remote Station Receiver.
or
UDACT Universal Digital Alarm
Communicator/Transmitter or Notifier 911AC
DACT for connection to a compatible
UL-listed remote station DACR.
“Wiring a Remote Station
Fire Alarm System” on
page 136
“Installing a UDACT” on
page 134 and “Installing
a Notifier 911AC” on
page 133.
NFPA 72
Proprietary Fire
Alarm System
NIB-96 Network Interface Board. The
NIB-96 must be installed in the receiving
system.
“NFPA 72 Proprietary
Fire Alarm Systems” on
page 138 and the NIB-96
Manual, Document
15666.
Technical Manuals Online! - http://www.tech-man.com

Notifier AFP-200 Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Auxiliary Power Output	24 VDC, 500 mA
Operating Temperature	32°F to 120°F (0°C to 49°C)
Display	80-character LCD
Power Supply	120 VAC, 60 Hz
Capacity	198 addressable devices
Notification Appliance Circuits	2
Relay Contacts	3 (Form-C)
Relative Humidity	93% non-condensing
