Notifier AFP-200 Installation Manual

Terminal Interface Protocol Using the CRT-2 for Alter Status
174 AFP-200 PN 15511:H2 10/14/2002
I.4.2 Accessing Alter Status Options
Access the Alter Status function from the CRT-2 by following these steps.
1. Turn on the CRT-2 connected to the control panel.
2. Press the Alter Status function key. The control panel displays the Alter Status
menu options:
3. Enter the Status Change Password. The factory default Status Change Password is
11111. The password does not display on the CRT-2. Five asterisks will appear in
place of the password:
The Alter Status Options menu appears:
From the Alter Status Options menu, you can select options 1-5.
I.4.3 Enable or Disable Detectors, Modules, or Bell Circuits
From the Alter Status menu, select Disable, option 1. Disable lets you enable or disable
detectors, modules, or bell Circuits:
Enter the following:
1. Enter the first letter to read one of the following:
• Detector
• Module
• Bell Circuit (NAC)
2. Enter the address or number of the device.
3. Press <Enter> and a display similar to the following will appear.
Enter Status Change Password or Escape to Abort
C
Press
*****
11111
W
Press
1=Disable 2=Sensitivity 3=Clear Verification 4=Clear History 5=Set Action/Alert
Disable/Enable D(Det.) / M(Mod.) / B(Bell ckt.), AA
1
Address or number
Press
Technical Manuals Online! - http://www.tech-man.com

Notifier AFP-200 Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Auxiliary Power Output	24 VDC, 500 mA
Operating Temperature	32°F to 120°F (0°C to 49°C)
Display	80-character LCD
Power Supply	120 VAC, 60 Hz
Capacity	198 addressable devices
Notification Appliance Circuits	2
Relay Contacts	3 (Form-C)
Relative Humidity	93% non-condensing
