Using the CRT-2 for Read Status Terminal Interface Protocol
AFP-200 PN 15511:H2 10/14/2002 171
Passwords: None
Requirements: Use with UL EDP-listed terminals, including personal computers
with Veri•Fire™ Upload/Download software or terminal emulation
software. Intended for terminals connected through modems,
including Notifier TPI modems connected through a public
switched telephone network.
Table 64 summarizes the functions available with the RemT mode:
Table 64 RemT Functions
I.3 Using the CRT-2 for Read Status
I.3.1 Overview
This section shows how to perform the Read Status functions from a CRT-2.
Table 65 Read Status Functions
I.3.2 Accessing Read Status Options
Access the Read Status function from the CRT-2 by following these steps.
1. Turn on the CRT-2, which is connected to the control panel.
2. Press the Read Status function key – F1. The control panel displays the Read Status
menu options:
Functions Lets you...
Read Status • Display the status of an individual point (detector, module, panel circuit, or
zone)
• Display a list of all the points in Alarm or trouble
• Display a list of all programmed points in the system
• Step through the history buffer event by event
• Display the entire history buffer
Alter Status N/A
Control
Functions
N/A
Function Lets you...
Read Point Read the status of any point in the system (detectors, modules, bell circuits,
software zones, and system parameters).
Alm/Tbl
Status
Display a list of all devices in the system that are in Alarm or trouble.
Read All
Points
Display a list of all points programmed in the system. This list will display the
status of all addressable detectors, modules, NACs, system parameters and
software zones.
History Step Step through the history buffer one event at a time.
History-All Send the entire history buffer to the CRT, from the most recent event to the
oldest event.
Read Point=1 Alm/Tbl Status=2 Read All Points=3 History Step=4/All=5
B
Press
