CBE Programming How to Program CBE
190 AFP-200 PN 15511:H2 10/14/2002
which puts Z05 into the CBE of D01 and M08. When detector D01 goes into alarm,
control module M08—and all devices and zones mapped to M08—also activate.
Figure 167 CBE Example 1
M.3.2 CBE Example 2
Program a Bell Circuit (B04) to activate a march time code.
1. Program Z98 (Code Type) to “March Time.” For instructions, refer to Section 3
“Programming”.
2. Program the Bell Circuit B04 to list Z98 in its CBE list.
3. When the Bell Circuit B04 activates, all devices connected to B04 will pulse with
the March Time code.
Figure 168 CBE Example 2
PROGRM@CONTROL
MODULE@ADDRESS@08
Z00@Z05@Z@@Z@@Z
@@@@@@@@@@@@@S*M08
PROGRM@SMOKE(PHOTO)
DETECTOR@ADDRESS@01
ZO3@Z05@Z@@@Z@@@Z@@
2.0%@@@@@@*P*@@@@D01
Both devices contain
zone Z05 in its CBE list
Software
Zone Z05
Detector
Zone Z05
Module
Zone Z05
PROGRM BELL CIRCUIT
PANEL CIRCUIT NO. 4
Z00@Z98@Z@@Z@@Z
SW B04
PRG@SOFTWARE@ZONE
CODE@TYPE:
MARCH@TIME
Z98
Z98 programmed for
March Time
B04 programmed with
Z98 in its CBE list
