Terminal Interface Protocol Operating Modes
170 AFP-200 PN 15511:H2 10/14/2002
Table 62 below summarizes the functions available with the Local Terminal mode:
Table 62 LocT Functions
I.2.2 Local Monitor Mode (LocM)
Functions, passwords, and special requirements of Local Monitor Mode (LocM) are:
Functions: Read Status, Alter Status, and Control Functions.
Passwords: User-defined password for Alter Status and Control functions.
Requirements: Password security feature for Control Functions eliminates the need
for mounting the CRT-2 in an enclosure.
Table 63 summarizes the functions available with the Local Monitor mode:
Table 63 LocM Functions
I.2.3 Remote Terminal Mode (RemT)
Functions, passwords, and special requirements of Remote Terminal Mode (RemT) are:
Functions: Read Status only. See Table 64.
Function Lets you...
Read Status Display the status of an individual point (detector, module, panel circuit, or
zone)
Display a list of all the points in alarm or trouble
Display a list of all programmed points in the system
Step through the history buffer event by event
Display the entire history buffer
Alter Status Disable/Enable an individual point
Change the sensitivity of a detector
Clear the verification counter of all detectors
Clear the entire history buffer
Set the AWACS™ alert and action levels
Control
Functions
Acknowledge
Alarm Silence
•System Reset
Drill
Function Lets you...
Read Status Display the status of an individual point (detector, module, panel circuit, or
zone)
Display a list of all the points in alarm or trouble.
Display a list of all programmed points in the system
Step through the history buffer event by event
Display the entire history buffer
Alter Status* Disable/Enable an individual point
Change the sensitivity of a detector
Clear the verification counter of all detectors
Clear the entire history buffer
Set the AWACS™ alert and action levels
Control
Functions*
Acknowledge
Alarm Silence
•System Reset
Drill
*Requires the user defined password for access.
