Operation How to Operate the Control Panel
106 AFP-200 PN 15511:H2 10/14/2002
When it lights The PRE-ALARM WARNING yellow LED flashes when a
non-acknowledged fire Pre-Alarm threshold is reached. The LCD display indicates if it
is an Alert or Action Pre-Alarm.
To turn off To turn off the PRE-ALARM WARNING LED, clear the pre-alarm
condition. Clearing an Action Pre-Alarm requires a system reset.
Supervisory Security
Function The SUPERVISORY SECURITY LED indicates one or more security
conditions in a combination fire/security protective signaling application. (For more
details on security applications, refer to Appendix E.)
When it lights The SUPERVISORY SECURITY yellow LED flashes when one or
more non-acknowledged supervisory alarm (such as a sprinkler valve tamper condition)
occurs. The
SUPERVISORY SECURITY LED also lights steady when you press the
ACKNOWLEDGE/STEP key.
To turn off Press the SYSTEM RESET key.
Alarm Silence
Function The ALARM SILENCE LED indicates that the ALARM SILENCE key is
pressed.
When it lights The ALARM SILENCE yellow LED lights steady when an alarm
condition occurs and the
ALARM SILENCE key is pressed.
To turn off The ALARM SILENCE LED turns off when you press the DRILL key or
the
SYSTEM RESET key.
System Trouble
Function The SYSTEM TROUBLE LED indicates one or more trouble conditions in
the system.
When it lights The SYSTEM TROUBLE yellow LED flashes when one or more
troubles occur and goes steady when you press the
ACKNOWLEDGE/STEP key. This LED
also lights (flash or steady) if the microprocessor watchdog timer fails (CPU FAIL).
To turn off Clear all trouble conditions.
4.3 How to Operate the Control Panel
This section contains instructions for operating the control panel under the following
operating conditions:
• Normal Operation
• Fire Alarm Operation
• Trouble Operation
• Supervisory Operation
