Before making copies
2-4 d-Color MF25
* Parts marked with an asterisk (*) are internal options and therefore are not shown in the illustra-
tion.
5 Desk DK-502 Allows this machine to be set up on the floor
Referred to as the “desk” throughout the manual.
6 Paper Feed Cabinet PC-103 The top tray can be loaded with up to 500 sheets of
paper, and the bottom tray can be used as storage.
Referred to as the “single paper feed cabinet”
throughout the manual.
7 Paper Feed Cabinet PC-203 Both the top and bottom trays can each be loaded
with up to 500 sheets of paper.
Referred to as the “double paper feed cabinet”
throughout the manual.
8 Paper Feed Cabinet PC-403 Can be loaded with up to 2,500 sheets of paper
Referred to as the “LCT” throughout the manual.
9 Finisher FS-603 Feeds out printed pages. The “Offset” setting (sep-
arating), Staple settings (stapling), and “Fold & Sta-
ple” function (binding) are available.
• In order to install the finisher, the main unit must
be installed on the desk, on the LCT, on the sin-
gle paper feed cabinet, or on the double paper
feed cabinet.
10 Punch Kit PK-501 Allows hole punching to be used if installed onto
finisher FS-603
Referred to as the “punch kit” throughout the man-
ual.
11 Finisher FS-501 Finishes printed pages according to the selected
Output setting (sorting or stapling), then feeds out
the pages
• In order to install the finisher, the main unit must
be installed on the desk, on the LCT, or on the
single paper feed cabinet or the double paper
feed cabinet.
12 Job Separator JS-601 Copy exit tray installed on finisher FS-501
Referred to as the “job separator” throughout the
manual.
13 Main unit The document is scanned by the scanner section,
and the scanned image is printed by the printer
section.
Referred to as the “machine”, the “main unit”, or
the “MF25” throughout the manual.
14 Fax Kit FK-502* Allows this machine to be used as a fax machine
15 Mount Kit MK-706* Required to mount the fax kit and local interface kit
16 Mount Kit MK-704* Installed when using this machine as a fax machine
17 Local Interface Kit EK-702* Used for making a local connection between this
machine and the computer
18 Dehumidifer Heater 1C* Installed in the paper feed cabinet or desk to pre-
vent humidity from collecting in the paper
