2
Before making copies
2-14 d-Color MF25
* Parts marked with an asterisk (*) are installed within the finisher and therefore are not shown in
the illustration.
7 Exit tray 2 Collects copies printed using the “Fold & Staple”
setting
8 Misfeed-clearing dial in folding
section
Turned when clearing paper misfeeds in the folding
section (See p. 5-29.)
9 Staple cartridge holder Removed from the stapler unit when clearing
jammed staples or replacing the staple cartridge
(See p. 9-20, p. 9-13.)
10 Misfeed-clearing dial 1 Turned when clearing paper misfeeds within the
finisher (See p. 5-29.)
11 Misfeed-clearing dial 2 Turned when clearing jammed staples or replacing
the staple cartridge, or for moving the staple car-
tridge holder out to the front (See p. 9-13.)
12 Stapler unit Pulled out when clearing jammed staples or replac-
ing the staple cartridge (See p. 9-20, p. 9-13.)
13 Front door Opened when clearing paper misfeeds or jammed
staples or when replacing the staple cartridge (See
p. 9-20, p. 9-13.)
14 Punch kit* Punches holes for filing printed pages when punch
kit PK-501 is installed onto finisher FS-603
No. Part Name Description
To Next Page
