6.4 Commands and Responses
E5EK
6--11
F A group
Bit Description [1] [0]
0 Heating side output
*3
ON OFF
*1
1 Cooling side output
*4
ON OFF
*1
2 Alarm output 1 ON OFF
*2
3 Alarm output 2 ON OFF
*2
4 Alarm output 3 ON OFF
*2
5 LBA output ON OFF
*2
6 HBA output ON OFF
*2
7 Run/Stop Stop Run
8 Auto/Manual Manual Auto
9 Remote/Local Remote Local
10 SP mode RSP LSP
11 Auto-tuning AT execution OFF
12
13
14
15
*1 Always “OFF” at linear output
*2 Always “OFF” when output is not assigned
*3 During position-proportional control, output is Open.
*4 During position-proportional control, output is Close.
F B group
Bit Description [1] [0]
0 Setting level 1 0
1 RAM write mode RAM Backup
2 Control output 1 type Linear Pulse
3 Control output 2 type Linear Pulse
4 EEPROM RAM¸EEPROM RAM = EEPROM
5 Input error ON OFF
6 A/D converter error ON OFF
7 CT overflow ON OFF
8 CT hold ON OFF
9 Potentiometer error ON OFF
10 RSP input error ON OFF
11
12
13
14
15
To return to setting level 0 from setting level 1, issue the “software reset” com-
mand.
If the parameter write command is issued for the setup and expansion modes in
setting level 0, an error occurs, and the end code (0D = Command cannot be
executed) is returned.
