Omron E5EK User Manual

CHAPTER 5 PARAMETERS
E5EK
5--8
Set point during SP
ramp
Conditions of Use
The remote SP function must be
enabled. When the remote SP function
is disabled, this function can be used
only when the SP ramp function is
enabled.
• Monitors the set point during SP ramp
• Matches the set point of the “PV/SP” parameter when the set point is not during
SP ramp.
Monitor Range
Unit
Local SP : Local SP setting lower limit to local SP setting upper limit EU
Remote SP : Remote SP lower limit to remote SP upper limit EU
F Related article
4.2 Operating Condition R estriction/SP ramp (page 4-6)
F Related parameters
“PV/SP” (level 0 mode)
“SP ramp time unit” “SP ramp set value” (level 2 mode)
“Set point upper limit” “Set p oint lower limit” (expansion mode)
“SP mode” (level 2 mode)
“Remote SP enable” “Remote SP upper limit” “Remote SP lower limit” (option
mode)
MV monitor (heat)
MV monitor (cool)
Conditions of Use
Control must be standard control or
heating and cooling control.
• This parameter cannot be set.
• Monitors the manipulated variable on the heating or cooling side.
• The manipulated variable in a standard control system is checked in the “MV
monito r (heat)” parameter.
• The “MV monitor (cool)” parameter can be used o nly during heating and cooling
control.
• MV monitor (heat)
Control
Monitor Range
Unit
Standard -5.0 to 105.0 %
Heating and cooling 0.0 to 105.0 %
• MV monitor (cool)
Control
Monitor Range
Unit
Heating and cooling 0.0 to 105.0 %
E5EK-AA2 AC100-240
E5EK-AA2 AC/DC24
Level 0 Mode
Function
Monitor
See
Function
Monitor
Model
