Omron E5EK - Process value; Set point; Remote SP monitor

E5EK
5--7
• Process value
Monitor Range
Unit
Scaling lower limit -10%FS to scaling upper limit +10%FS
EU
During temperature input, the range of the currently selected sensor is taken as
the monitor range.
• Set point
Setting Range/Monitor Range
Unit Default
Local SP : Local SP lower limit to local SP setting upper limit
EU 0
Remote SP: Remote SP lower limit to remote SP upper limit
EU -
F Related article
3.7 Adjusting Control Operation (page 3-14)
F Related parameters
“Inpu t type ” “S ca ling upper limit” “Sca ling lower limit ” “De cim a l point ” (se t up
mode)
“SP setting upper limit” “SP setting lower limit” (expansion mode)
“SP mode” (level 2 mode)
“Remote SP enable” “Remote SP upper limit” “Remote SP lower limit” (option
mode)
Remote SP monitor
Conditions of Use
The controller must be in the local SP
mode with the remote SP function
enabled.
• Monitors remote SP in the local SP mode.
Monitor Range
Unit
Remote SP lower limit to Remote SP upper limit
EU
F Related article
4.2 Operating Condition R estrictions/SP ramp (page 4 -6)
F Related parameters
“SP mode” (level 2 mode)
“Remote SP enable” “Remote SP lower limit” “Remote SP upper limit” (option
mode)
Level 0 Mode
Comment
See
Level 0 Mode
Function
Monitor
See
