APPENDIX
E5EK
A-- 2
SPECIFICATIONS
JRatings
AC100-240V type AC/DC24V type
Supply Voltage
AC100-240V , 50/60 Hz~ AC/DC24V , 50/60Hz
Power Consumption 15VA 12VA, 8W
Operating Voltage
Range
85% to 110% of rated supply voltage
Main Input
Thermocouple : K, J, T, E, L, U, N, R, S, B, W, PLII
Platinum resistance thermometer : JPt100, Pt100
Voltage input : 4 to 20mA, 0 to 20mA (Input impedance 150Ω)
Current input : 1 to 5V, 0 to 5V, 1 to 10V (Input impedance 1MΩ)
Sub-Input
CT input: E54-CT1, E54-CT3
Potentiometer: 100Ω to 2.5kΩ
Remote SP input: 4 to 20 mA (Input impedance 150 Ω)
Control Output According to output unit (see “Output Unit Ratings and Characteristics”)
Auxiliary Output SPST-NO, 3A at 250 VAC (resistive load)
Control Method Advanced PID or ON/OFF control
Setting Method Digital setting using front panel keys
Indication Method 7-segment digital display, Bar graph and LEDs
Other Functions According to option unit (see ”Option Unit Ratings and Characteristics”)
Ambient Temperature
Operating : -10°Cto55°C (with no icing)/3-y ear warranty period: -10°Cto50°C
Storage : -25°Cto65°C (with no icing)
Ambient Humidity 35% to 85%
*1 Thermocouple W is W/Re5-26.
*2 The following table shows the setting ranges and indication ranges for each of the inputs.
Input
Setting Range Indication Range
JPt100 -199.9 to 650.0(_C) /-199.9 to 999.9(_F) -199.9 to 735.0(_C) /-199.9 to 999.9(_F)
Pt100 -199.9 to 650.0(_C) /-199.9 to 999.9(_F) -199.9 to 735.0(_C) /-199.9 to 999.9(_F)
K1 -200 to 1300(_C) /-300 to 2300(_F) -350 to 1450(_C) /-560 to 2560(_F)
K2 0.0 to 500.0(_C) /0.0 to 900.0(_F) -50.0 to 550.0(_C) /-90.0 to 990.0(_F)
J1 -100 to 850(_C) /-100 to 1500(_F) -195 to 945(_C) /-260 to 1660(_F)
J2 0.0 to 400.0(_C) /0.0 to 750.0(_F) -40.0 to 440.0(_C) /-75.0 to 825.0(_F)
T -199.9 to 400.0(_C) /-199.9 to 700.0(_F) -199.9 to 460.0(_C) /-199.9 to 790.0(_F)
E 0 to 600(_C) /0 to 1100(_F) -60 to 660(_C) /-110 to 1210(_F)
L1 -100 to 850(_C) /-100 to 1500(_F) -195 to 945(_C) /-260 to 1660(_F)
L2 0.0 to 400.0(_C) /0.0 to 750.0(_F) -40.0 to 440.0(_C) /-75.0 to 825.0(_F)
U -199.9 to 400.0(_C) /-199.9 to 700.0(_F) -199.9 to 460.0(_C) /-199.9 to 790.0(_F)
N -200 to 1300(_C) /-300 to 2300(_F) -350 to 1450(_C) /-560 to 2560(_F)
R 0 to 1700(_C) /0 to 3000(_F) -170 to 1870(_C) /-300 to 3300(_F)
S 0 to 1700(_C) /0 to 3000(_F) -170 to 1870(_C) /-300 to 3300(_F)
B 100 to 1800(_C) /300 to 3200(_F) -70 to 1970(_C) /10 to 3490(_F)
W 0 to 2300(_ C) /0 to 4100(_F) -230 to 2530(_C) /-410 to 4510(_F)
PLII 0 to 1300(_C) /0 to 2300(_F) -130 to 1430(_C) /-230 to 2530(_F)
4to20mA
0to20mA
1to5V
0to5V
0to10V
One of following ranges depending on results of
scaling
-1999 to 9999
-199.9 to 999.9
-19.99 to 99.99
-1.999 to 9.999
-10 to 110% of setting range. Note, however that
max. value is -1999 to 9999
*1, *2
