1.1 Names of parts
E5EK
1--3
JAbout the displays
Displays the p rocess value or parameter symbols.
Displays the set point, manipulated variable or p arameter settings.
• OUT1 : Lit when the pulse output function assigned to “control
output 1” is ON.
• OUT2 : Lit when the pulse output function assigned to “control
out- put 2” is ON.
• SUB1 : Lit when the output function assigned to “auxiliary output
1” is ON.
• SUB2 : Lit when the output function assigned to “auxiliary
output 2” is ON.
• MANU : Lit in the manual operation mode.
• STOP : Lit when operation has stopped.
• RMT : Lit during remote operation.
• RSP : Lit during remote SP operation.
• AT : Flashes during auto-tuning.
The following describes basic key operations.
Each press of this key switches between the auto and manual opera-
tions.
The functions o f this key change according to how long it is pressed. If
the key is pressed for less than one second, the parameters are switched.
If the key is pressed for one second or more, the menu display appears.
In key operations from here on, “press the key” refers to pressing the
key for less than one second.
For details on parameter switching and menu display items, see page
1-8.
Each press of the
key increments or advances the values or settings
on the No.2 display, while each press of the
key decrements or
returns the values or settings on the No.2 display.
Functions vary, for example, when the
A/M
key is held down simulta-
neously with the display key, or a key is held down continuously. For
details, see page 1-8. Also, chapters 3 and 4 describe examples using
various key combinations.
F No.1 display
F No.2 display
F Operation indica-
tors
JHow to use keys
F key
A/M
F key
F key
