102 eCobra User's Guide 14402-000 Rev. F
6.3 Warning Labels
l
Gravity/Brake Release Label, 18272-000
This label warns about the possibility of a robot joint dropping suddenly when the
brake release is pressed because of gravity. In the case of the eCobra, this applies to the
quill and tool flange.
Figure 6-3. Brake Release/Gravity Label
l
Lifting Point Label, 08613-000
This label is partially around the eyebolt, marking that as a point to lift from.
Figure 6-4. Lifting Eyebolt Label
