Chapter 3: Robot Installation
3.5 Environmental and Facility Requirements
The robot system installation must meet the operating environment requirements shown in the
following table.
Table 3-2. Robot System Operating Environment Requirements
Ambient temperature 5 to 40° C (41 to 104° F)
Shipping/storage temperature –25 to 55° C (-13 to 131° F)
Humidity 5% to 90%, non-condensing
Altitude up to 2000 m (6500 ft)
Pollution degree 2
Robot protection class IP20 (NEMA Type 1)
IP65 Versions IP65
Cleanroom rating, cleanroom models only ISO 4, Fed Reg Class 10
NOTE: For robot dimensions, see Dimension Drawings on page 153.
3.6 Mounting an Upright eCobra Robot
This section applies to the eCobra 600 and eCobra 800 robots, but not the eCobra 800 Inverted
robot.
Figure 3-1. eCobra 800 Robot on a Transportation Pallet
14402-000 Rev. F eCobra User's Guide 27
