4.1 System Cables, without SmartController EX
The figure above includes the optional T20 pendant, optional SmartVision MX industrial PC,
and optional PLC. These items may not be present in your system.
NOTE: For additional system grounding information, see Connecting 24 VDC
Cable on page 52.
List of Cables and Parts
Open the Accessory box and locate the eAIB XSYSTEM cable. Connect the cables and peri-
pherals as shown in the preceding figure. Installation steps are covered in Cable Installation
Overview on page 38.
Table 4-1. Cables and Parts Description (without SmartController EX)
Item Description Part #
Standard Option
User-
supplied
Notes
A eAIB XSYSTEM Cable
Assembly
13323-
000
X
B User E-Stop, Safety
Gate
n/a X
C XUSR Jumper Plug 04736-
000
X Required if no
E-stop, safety
gate or muted
safety gate
used.
D Front Panel 90356-
10358
X X Front Panel (D)
or Front Panel
Jumper Plug (F)
must be used.
E Front Panel Cable 10356-
10500
X X
F Front Panel Jumper
Plug
10053-
000
X Front Panel (D)
or Front Panel
Jumper Plug (F)
must be used.
G XMCP Jumper Plug 10052-
000
X XMCPJumper
Plug (G), T20
Pendant
Bypass Plug
(H), or T20
Pendant
Assembly
(W)must be
used.
H T20 Pendant Bypass
Plug
10048-
000
X XMCPJumper
Plug (G), T20
Pendant
