42 eCobra User's Guide 14402-000 Rev. F
4.2 System Cables, with SmartController EX
Part Cable and Parts
List
Part # Standard Option
User-
supplied
Notes
Bypass Plug (H), or
T20 Pendant (W)
must be used.
H T20 Pendant Bypass
Plug
10048-
000
X XMCP Jumper Plug
(G), T20 Pendant
Bypass Plug (H), or
T20 Pendant (W)
must be used.
I T20 Pendant Adapter
Cable
10051-
003
X
The following three items are available, as an option, in the power supply/cable kit 90565-010
J VAC Power Cable 04118-
000
X X 200-240 VAC,
single phase
K 24 VDC Power Cable 04120-
000
X X
L 24 VDC, 6 A Power
Supply
04536-
000
X X 85 - 264
VACuniversal input
M Ethernet Cable,
Switch (if used) ->
SmartController EX
n/a X
N Ethernet Cable,
Switch (if used) ->
SmartVision MX, if
used
n/a X
O IEEE 1394 cable 13632-
045
X
P Camera and cable n/a X X
Q Robot Interface Panel n/a X
R User-supplied ground
wire
n/a X
S PCrunning ACE Soft-
ware
n/a X
T Ethernet Switch n/a X
U Ethernet Cable - PC -
> ethernet switch
n/a X
V PLC (optional) X X
W T20 Pendant
Assembly
10054-
010
X Optional T20 Pend-
ant Kit (10046-
010) includes items
W, H, and I.
