D Inverter Status 1 (Register 002C Hex)
Bit No. Function
0 During RUN (1: During RUN)
1 Zero speed (1: Zero speed)
2 Frequency agree (1: Frequency agree)
3 Warning (Nonfatal error) (1: Warning)
4
Frequency detection 1 (1: Output frequency x n095)
5
Frequency detection 2 (1: Output frequency y n095)
6 Inverter ready (1: Ready)
7 UV (1: UV)
8 Base block (1: Base block)
9 Frequency reference mode (1: Other than communications)
10 RUN command mode (1: Other than communications)
11 Overtorque detection (1: Overtorque detection)
12 Not used.
13 Fault retry (1: Fault retry)
14 Fault (1: Fault)
15 Communications time-over: No normal communications for 2 s or more
(1: Communications time-over detecting)
D Output Terminal Status (Register 002D Hex)
Bit No. Function
0 Multi-function contact output terminal MA (1: ON)
1 Multi-function photocoupler output terminal 1 (P1) (1: ON)
2 Multi-function photocoupler output terminal 2 (P2) (1: ON)
3 to 15 Not used.
D Inverter Status 2 (Register 002E Hex)
Bit No. Function
0 Frequency reference loss
1 to 15 Not used.
D Communications Error (Register 003D Hex)
Bit No. Function
0 CRC error (1: Error)
1 Data length error (1: Error)
2 Not used.
3 Parity error (1: Error)
4 Overrun error (1: Error)
5 Framing error (1: Error)
6 Communications time-over (1: Error)
7 to 15 Not used.
Communications Chapter 7

Omron SYSDRIVE 3G3MV SERIES Specifications

General

Model	SYSDRIVE 3G3MV SERIES
Category	Inverter
Input Frequency	50/60 Hz
Output Frequency	0.1 to 400 Hz
Cooling Method	Forced Air Cooling
Input Voltage	200 to 240 VAC, 380 to 480 VAC
Horsepower Range	0.1 to 15 HP
Power Range	0.1 to 11 kW
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5 to 95% RH (non-condensing)
Vibration	5.9 m/s² or less
Voltage Class	200V, 400V
