Page #215 background imageLoading...
Page #215 background image
7-25
D Warning Status (Register 002A Hex)
Bit No. Function
0 STP (Emergency stop)
1 SER
2 EF
3 BB
4 OL3
5 OH
6 OV
7 UV
8 FAN
9 to 11 Not used.
12 OH3
13 FBL
14 STP (Emergency stop)
15 Not used.
D Input Terminal Status (Register 002B Hex)
Bit No. Function
0 Multi-function input terminal 1 (S1) (1: ON)
1 Multi-function input terminal 2 (S2) (1: ON)
2 Multi-function input terminal 3 (S3) (1: ON)
3 Multi-function input terminal 4 (S1) (4: ON)
4 Multi-function input terminal 5 (S5) (1: ON)
5 Multi-function input terminal 6 (S6) (1: ON)
6 Multi-function input terminal 7 (S7) (1: ON)
7 to 15 Not used.
Communications Chapter 7
